Tractor · 1986Unverified
Yanmar YM169
Yanmar YM169 — Sub-Compact Utility tractor · 16 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
589 kg
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Sub-Compact Utility tractorReference
Two- or four-wheel driveReference
Mechanical drum brakesReference
Open operator station.Reference
Variants
YM1692WDReference
YM169D4WDReference
Engine
Yanmar 0.9L 3-cyl dieselReference
Fuel tank15.9 LReference
Engine11.9 kWReference
Yanmar 3T72HA-AReference
dieselReference
3-cylinderReference
liquid-cooled vertical inlineReference
Displacement0.9 LReference
Bore/Stroke72 x 72 mmReference
Power11.9 kWReference
Fuel systemBosch YPER-0707 injection pumpReference
Pre-heatingthermostartReference
Compression23:1Reference
Rated RPM2600Reference
Torque49.9 NmReference
Torque RPM1800Reference
Firing order1-3-2Reference
Starter volts12Reference
Starter power1.3 kWReference
Oil capacity3.2 LReference
Intake valve clearance0.198 mmReference
Exhaust valve clearance0.198 mmReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
Oil capacity9.5 LReference
PTO & Hydraulics
PTO (claimed)11.9 kWReference
Typegear pumpReference
Pressure107.8 barReference
Total flow13.0 lpmReference
Rear TypeIReference
Rear lift499 kgReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2255Reference
Engine RPM770@2255Reference
Dimensions
Wheelbase125 cmReference
Weight589 kgReference
Front tire4.50-10Reference
2WD Rear tire8-16Reference
2WD Standard tires (ag)Front: 4.50-10. Rear: 8-16Reference
4WD Standard tires (ag)Front: 5-12. Rear: 8-16Reference
Lawn/turf front6-12Reference
Lawn/turf rear8-16Reference
Length213 cmReference
Length248 cmReference
Width97 cmReference
Height129 cmReference
Height (hood)105 cmReference
2WD Ground clearance26 cmReference
4WD Ground clearance23 cmReference
2WD Front tread76 cmReference
4WD Front tread74 cmReference
Rear tread70 to 85 cmReference
Electrical
GroundnegativeReference
Charging amps15Reference
Charging volts12Reference
Battery volts12Reference
Speeds
With 8-16 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
