The Yanmar YM1720 is a compact tractor model rated at 17 hp. Manufactured from 1982 to 1983, it is equipped with a 3-cylinder diesel liquid-cooled engine, delivering power through four-wheel drive via a powershift transmission. The tractor weighs 939 kg. It is suitable for tasks covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
939 kg
Catalogue coverage
Variants represented
2
Richest spec table
29 rows
Recorded power
17 hp
Recorded weight
939 kg
Transmissions
9-speed partial power shift
Production years
1982-1983
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Open operator station.Reference
Variants
YM17022WD gearReference
YM1702D4WD gearReference
YM17202WD power shiftReference
YM1720D4WD power shiftReference
Engine
Yanmar 1.0L 3-cyl dieselReference
Engine12.7 kWReference
Yanmar 3T75UReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Bore/Stroke75 x 75 mmReference
Power12.7 kWReference
Starter volts12Reference
Transmission
9-speed partial power shiftReference
12-speed creeperReference
Typepartial power shiftReference
Gears9 forward and 3 reverseReference
Three power shift gears, plus reverse, with three ranges.Reference
TypecreeperReference
Gears12 forward and 4 reverseReference
Dimensions
Weight939 kgReference
Length261 cmReference
Width111 cmReference
Height175 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
