Tractor · 1972Unverified

Yanmar YM2200

Name: Yanmar YM2200
Brand: Yanmar

Yanmar YM2200 — Compact Utility tractor · 22 hp. Reference specifications; pending source verification.

The Yanmar YM2200 is a tractor with an output of 22 hp, placing it among the more compact options in its class. Originally produced from 1972 to 1976, this model features a 2-cylinder diesel liquid-cooled engine, transmitting power through a two-wheel drive system with an 8-speed gearbox. The listed weight of the YM2200 is 949 kg, and it is suitable for tasks requiring up to 200 acres of coverage.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

22 hp

Weight

949 kg

Catalogue coverage

Variants represented

Richest spec table

29 rows

Recorded power

22 hp

Recorded weight

949 kg

Transmissions

8-speed gear

Production years

1972-1976

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerYanmarReference

Compact Utility tractorReference

Two-wheel driveReference

Open operator station.Reference

Engine

Yanmar 1.1L 2-cyl dieselReference

Engine16.4 kWReference

Yanmar 2TR22Reference

dieselReference

2-cylinderReference

liquid-cooledReference

Displacement1.1 LReference

Power16.4 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

8-speed gearReference

TypegearReference

Gears8 forward and 2 reverseReference

PTO & Hydraulics

Rear PTO Type540 (1.375)Reference

Engine RPM465@2600Reference

Engine RPM587@2600Reference

Engine RPM951@2600Reference

Engine RPM1200@2600Reference

Dimensions

Weight949 kgReference

Length270 cmReference

Width125 cmReference

Height187 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
