Tractor · 1977Unverified
Yanmar YM2210
Yanmar YM2210 — YM10 Series · 22 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
2094 to 2205 pounds
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Open operator station.Reference
Variants
YM22102WD power shiftReference
YM2210D4WD power shiftReference
Engine
Yanmar 1.1L 2-cyl dieselReference
Fuel tank23.8 LReference
Engine16.2 kWReference
Yanmar 2T90Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke90 x 90 mmReference
Power16.2 kWReference
Rated RPM2600Reference
Starter volts12Reference
Image courtesy of Evan BarberReference
Transmission
15-speed partial power shiftReference
Typepartial power shiftReference
Gears15 forward and 5 reverseReference
Five ranges with three power shift gears (plus reverse) per range.Reference
PTO & Hydraulics
Rear PTOtransmissionReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2200Reference
Engine RPM1000@2200Reference
Dimensions
2WD Wheelbase154 cmReference
4WD Wheelbase160 cmReference
Weight2094 to 2205 poundsReference
Front tire4.00-15Reference
2wD Rear tire9.5-24Reference
2wD Standard tires (ag)Front: 4.00-15. Rear: 9.5-24Reference
4WD Standard tires (ag)Front: 6-14. Rear: 9.5-24Reference
Length278 cmReference
Width116 cmReference
2WD Height184 cmReference
4WD Height184 cmReference
2WD Weight949 kgReference
4WD Weight1000 kgReference
2WD Ground clearance36 cmReference
4WD Ground clearance32 cmReference
2WD Front tread88 cmReference
4WD Front tread91 cmReference
Rear tread102 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
