Tractor · 1981Unverified
Yanmar YM226
Yanmar YM226 — Compact Utility tractor · 19 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
19 hp
Max power
11.5 kW
Weight
1724 to 2300 pounds
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Built in JapanReference
Original price was $9,000 in 1991Reference
Two- or four-wheel driveReference
Manual steeringReference
Drum brakesReference
Two-post fixed ROPS.Reference
Variants
YM2202WD gear shiftReference
YM220D4WD gear shiftReference
YM2262WD power shiftReference
YM226D4WD power shiftReference
Engine
Yanmar 1.1L 3-cyl dieselReference
Fuel tank20.1 LReference
Engine16.4 kWReference
Drawbar (tested)11.5 kWReference
Yanmar 3T75HAReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke75 x 85 mmReference
Power16.4 kWReference
Air cleanerpaper elementReference
Compression22.5:1Reference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Power at rated engine speed14.5 kWReference
Max power11.5 kWReference
Transmission
9-speed three-speed power shiftReference
Typethree-speed power shiftReference
Gears9 forward and 3 reverseReference
Clutchdry discReference
Three power shift gears, plus reverse, in three ranges.Reference
PTO & Hydraulics
PTO (tested)14.5 kWReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)529 kgReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2400Reference
Power at rated PTO speed13.3 kWReference
Dimensions
Wheelbase155 cmReference
Weight1724 to 2300 poundsReference
Front tire6.00-14Reference
2WD Rear tire11.2-24Reference
2WD Standard tires (ag)Front: 6.00-14. Rear: 11.2-24Reference
4WD Standard tires (ag)Front: 6-14. Rear: 9.5-24Reference
Lawn/turf front25x8.50-14Reference
Lawn/turf rear13.6-16.1Reference
Length274 cmReference
2WD Width136 cmReference
4WD Width136 cmReference
Clearance (drawbar)36 cmReference
2WD Front tread96 cmReference
4WD Front tread92 cmReference
Rear tread100 to 120 cmReference
2WD782 kgReference
4WD818 kgReference
4WD Operating1043 kgReference
Yanmar YM226 attachments
60" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
60" Mower deck
Typemid-mount Yanmar YCM60AReference
Type3-bladeReference
Cutting width152 cmReference
Cut height5 to 10 cmReference
Yanmar YBH770 Backhoe
Backhoe typeYanmar YBH770 BackhoeReference
Bucket width25 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width60 cmReference
Digging depth231 cmReference
Loading height172 cmReference
Swing Arc180°Reference
Bucket force1179 kgReference
Dipperstick force1031 kgReference
Yanmar YM226 Height
ROPS219 cmReference
2WD Exhaust180 cmReference
4WD Exhaust180 cmReference
Test results
Diesel 9-speed 4WDJune 10 - 21, 1982Link: Nebraska Tractor Test 1442 fileReference
PTO performanceReference
Fuel use4.9 l/hourReference
Fuel use4.5 l/hourReference
Drawbar performanceReference
Gear 3-1 used for power test.Reference
Max pull1199 kgReference
Gear 2-1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
