Tractor · 1984Unverified
Yanmar YM236
Yanmar YM236 — Compact Utility tractor · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
1903 to 2066 pounds
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Two-post ROPS.Reference
Engine
Yanmar 1.0L 3-cyl dieselReference
Engine17.2 kWReference
Yanmar 3T75Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Bore/Stroke75 x 75 mmReference
Power17.2 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
9-speed power shiftReference
Typepower shiftReference
Gears9 forward and 3 reverseReference
PTO & Hydraulics
PTO (claimed)14.9 kWReference
Pressure151.7 barReference
Pump flow14.4 lpmReference
Rear TypeIReference
Rear lift (at ends)529 kgReference
Rear lift (at 24"/610mm)370 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Dimensions
Weight1903 to 2066 poundsReference
Front tire5.00-15Reference
2WD Rear tire11.2-24Reference
2WD Standard tires (ag)Front: 5.00-15. Rear: 11.2-24Reference
4WD Standard tires (ag)Front: 7-14. Rear: 11.2-24Reference
Length274 cmReference
Width126 cmReference
Height182 cmReference
2WD Weight863 kgReference
4WD Weight937 kgReference
Ground clearance36 cmReference
Speeds
With 11.2-24 rear tiresReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
