The Yanmar YM2820 is a compact tractor model with a rated output of 28 hp. It was manufactured from 1982 to 1983. The tractor is equipped with a 3-cylinder diesel liquid-cooled engine, which drives four-wheel drive via a powershift transmission. Its listed weight is 1735 kg and it is suitable for applications involving up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
1735 kg
Catalogue coverage
Variants represented
2
Richest spec table
24 rows
Recorded power
28 hp
Recorded weight
1735 kg
Transmissions
12-speed partial power shift
Production years
1982-1983
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Open operator station.Reference
Variants
YM28202WDReference
YM2820D4WDReference
Engine
Yanmar 3-cyl dieselReference
Engine20.9 kWReference
YanmarReference
dieselReference
3-cylinderReference
liquid-cooledReference
Power20.9 kWReference
Starter volts12Reference
Transmission
12-speed partial power shiftReference
Typepartial power shiftReference
Gears12 forward and 4 reverseReference
Three power shift gears, plus reverse, with four ranges.Reference
Dimensions
Weight1735 kgReference
Length317 cmReference
Width147 cmReference
Height190 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
