Tractor · 1981Unverified
Yanmar YMG1800
Yanmar YMG1800 — Compact Utility tractor · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
1676 to 1786 pounds
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Two-wheel driveReference
Dry brakesReference
Open operator station.Reference
Variants
YMG1800D4WDReference
Engine
Yanmar 1.3L 3-cyl dieselReference
Fuel tank20.4 LReference
Engine13.3 kWReference
Yanmar 3T80U-SBReference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.3 LReference
Bore/Stroke80 x 85 mmReference
Power13.3 kWReference
Rated RPM2400Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
Rear TypeJIS0Reference
Rear PTO Type540 (1.375)Reference
Engine RPM550@2400Reference
Engine RPM784@2400Reference
Engine RPM1096@2400Reference
Dimensions
Wheelbase147 cmReference
Weight1676 to 1786 poundsReference
Front tire5-14Reference
2WD:4.00-12:8.3-22 4WD} Rear tire8.3-22Reference
2WD Standard tires (ag)Front: 5-14. Rear: 8.3-22Reference
Length242 cmReference
Width114 cmReference
Height (exhaust)178 cmReference
2WD Weight760 kgReference
4WD Weight810 kgReference
2WD Ground clearance32 cmReference
4WD Ground clearance29 cmReference
2WD Front tread84 cmReference
4WD Front tread91 cmReference
Rear tread89/102 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH70Reference
Speeds
With 8.3-22 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
