Tractor · 1981Unverified

Yanmar YMG2000

Name: Yanmar YMG2000
Brand: Yanmar

Yanmar YMG2000 — Compact Utility tractor · 20 hp. Reference specifications; pending source verification.

The Yanmar YMG2000 is a tractor with a rated output of 20 hp — making it one of the more compact options in its class. This model was produced from 1981 to 1983. It is powered by a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a 12-speed gearbox. Listed weight is 1698 to 1808 pounds, and it is aimed at jobs of around up to 200 ac. The available specification table below shows both UK and US units.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

20 hp

Weight

1698 to 1808 pounds

Catalogue coverage

Variants represented

Richest spec table

45 rows

Recorded power

20 hp

Recorded weight

770 kg

Transmissions

12-speed

Production years

1981-1983

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerYanmarReference

Compact Utility tractorReference

Two-wheel driveReference

Dry brakesReference

Open operator station.Reference

Variants

YMG2000D4WDReference

Engine

Yanmar 1.3L 3-cyl dieselReference

Fuel tank20.4 LReference

Engine14.7 kWReference

Yanmar 3T80U-SAReference

dieselReference

3-cylinderReference

liquid-cooled inlineReference

Displacement1.3 LReference

Bore/Stroke80 x 85 mmReference

Power14.7 kWReference

Rated RPM2400Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speedReference

Gears12 forward and 4 reverseReference

PTO & Hydraulics

Rear TypeJIS0Reference

Rear PTO Type540 (1.375)Reference

Engine RPM550@2400Reference

Engine RPM784@2400Reference

Engine RPM1096@2400Reference

Dimensions

Wheelbase147 cmReference

Weight1698 to 1808 poundsReference

Front tire5-14Reference

2WD:4.00-12:8.3-24 4WD} Rear tire8.3-24Reference

2WD Standard tires (ag)Front: 5-14. Rear: 8.3-24Reference

Length245 cmReference

Width114 cmReference

Height (exhaust)179 cmReference

2WD Weight770 kgReference

4WD Weight820 kgReference

2WD Ground clearance34 cmReference

4WD Ground clearance29 cmReference

2WD Front tread84 cmReference

4WD Front tread91 cmReference

Rear tread89/102 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Battery AH70Reference

Speeds

With 8.3-24 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
