Tractor · 2016Unverified
Yanmar YT235
Yanmar YT235 — YT2 Series · 34 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
34 hp
Weight
2558 to 2910 pounds
Hover a source tag to verify
Overview
ManufacturerYanmarReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab optional with air-conditioning.Reference
Variants
YT235ROPSReference
YT235CcabReference
Engine
Yanmar 1.6L 3-cyl dieselReference
Fuel tank28.0 LReference
Engine (gross)25.5 kWReference
Engine (net)23.9 kWReference
Yanmar 3TNV88Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke86 x 90 mmReference
EmissionsTier IVReference
Power (net)23.9 kWReference
Power (gross)25.5 kWReference
Rated RPM2800Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
PTO (claimed)20.1 kWReference
Pump flow26.9 lpmReference
Steering flow15.5 lpmReference
Rear TypeIReference
Rear lift (at ends)1000 kgReference
Rear lift (at 24"/610mm)800 kgReference
Rear PTO Type540Reference
Mid PTO Type2013Reference
Dimensions
Wheelbase165 cmReference
Weight2558 to 2910 poundsReference
Front tire6-14Reference
Rear tire9.5-22Reference
Weight128 kgReference
Standard tires (ag)Front: 6-14. Rear: 9.5-22Reference
Lawn/turf front9.5-22Reference
Lawn/turf rear13.6-16Reference
Industrial front13.6-16Reference
Industrial rear15-19.6Reference
Length296 cmReference
Width148 cmReference
Height (ROPS)226 cmReference
Height (cab)212 cmReference
ROPS Weight1160 kgReference
Cab Weight1319 kgReference
Ground clearance27 cmReference
Yanmar YT235 attachments
60" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
ROPS Charging amps40Reference
Cab Charging amps55Reference
Battery CCA540Reference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
60" Mower deck
Typemid-mount Yanmar M60FReference
Type3-bladeReference
Cutting width152 cmReference
Cut height2 to 10 cmReference
Yanmar B75 Backhoe
Backhoe typeYanmar B75 BackhoeReference
Transport height187 cmReference
2-Foot flat digging depth228 cmReference
Reach from pivot302 cmReference
Loading height185 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1507 kgReference
Dipperstick force994 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
