Lawn Tractor · 1985Unverified
Yard-Man 13705
Yard-Man 13705 — Lawn tractor · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
280 kg
Hover a source tag to verify
Overview
ManufacturerYard-Man (a part of MTD)Reference
Lawn tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
14HP Briggs & Stratton 655cc 2-cyl gasolineReference
Fuel tank11.4 LReference
Briggs & Stratton 400000Reference
gasolineReference
2-cylinderReference
air-cooledReference
Displacement40 ciReference
Bore/Stroke87 x 55 mmReference
Power10.4 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
7-speed gearReference
Typebelt-driven gearReference
Gears7 forward and 1 reverseReference
Dimensions
Weight280 kgReference
Front tire15.00x6.00Reference
Rear tire18.00x9.50Reference
Lawn/turf front15.00x6.00Reference
Lawn/turf rear18.00x9.50Reference
Yard-Man 13705 attachments
44" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
44" mid-mount mower deckReference
SnowblowerReference
BladeReference
44" Mower deck
Typemid-mount Yard-ManReference
Type2-bladeReference
Cutting width111 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
