Lawn Tractor · 1977Unverified
Yard-Man 13795 830
Yard-Man 13795 830 — Riding lawn mower · 8 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
8 hp
Weight
136 kg
Hover a source tag to verify
Overview
ManufacturerYard-Man (a part of MTD)Reference
Riding lawn mowerReference
Two-wheel driveReference
Manual steeringReference
Disc brakesReference
Open operator station.Reference
Engine
8HP Briggs & Stratton 318cc 1-cyl gasolineReference
Fuel tank9.5 LReference
Briggs & StrattonReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement19.44 ciReference
Bore/Stroke76 x 70 mmReference
Power6.0 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
5-speed gearReference
Typebelt-driven gearReference
Gears5 forward and 1 reverseReference
Dimensions
Weight136 kgReference
Front tire11x4Reference
Rear tire14.50x4.50Reference
Lawn/turf front11x4Reference
Lawn/turf rear14.50x4.50Reference
Shipping weight136 kgReference
Yard-Man 13795 attachments
30" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
30" Mower deck
Typemid-mount Yard-ManReference
Type1-blade with manual liftReference
Cutting width76 cmReference
Cut height3 to 8 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
