Lawn Tractor · 1984Unverified
Yard-Man 14843
Yard-Man 14843 — Garden tractor · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
317 kg
Hover a source tag to verify
Overview
ManufacturerYard-Man (a part of MTD)Reference
Garden tractorReference
Two-wheel driveReference
Manual steeringReference
Disc brakesReference
Open operator station.Reference
Engine
18HP Briggs & Stratton 693cc 2-cyl gasolineReference
Fuel tank9.5 LReference
Briggs & Stratton 420000Reference
gasolineReference
2-cylinderReference
air-cooled vertical-shaftReference
Displacement42.33 ciReference
Bore/Stroke87 x 58 mmReference
Power13.4 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
Typesleeve hitchReference
Dimensions
Weight317 kgReference
Front tire16.00x6.50Reference
Rear tire23.00x9.50Reference
Lawn/turf front16.00x6.50Reference
Lawn/turf rear23.00x9.50Reference
Shipping weight317 kgReference
Yard-Man 14843 attachments
44" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
44" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
