Snowmobile · 1970Unverified
Yard-Man Sno-Cub
Yard-Man Sno-Cub — Snowmobile · 5 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
5 hp
Weight
56 kg
Hover a source tag to verify
Overview
ManufacturerYard-ManReference
SnowmobileReference
Built in Jackson, Michigan, USAReference
Original price was $429 in 1970Reference
TrackedReference
Manual steeringReference
Suspensionbogie wheelsReference
Engine
4.75HP JLO 989cc 1-cyl gasolineReference
Fuel tank4.2 LReference
JLO L99Reference
gasolineReference
1-cylinderReference
air-cooled horizontal-shaftReference
Displacement60.4 ciReference
Bore/Stroke55 x 42 mmReference
Power3.5 kWReference
Fuel systemTillotson HL-2708 carburetorReference
Compression6.1:1Reference
Rated RPM5500Reference
Starter typemanual recoilReference
SparkplugBosch M240T1Reference
Sparkplug gap0.457 mmReference
Dimensions
Weight56 kgReference
Length158 cmReference
Width78 cmReference
Height72 cmReference
Track width26 cmReference
Track length on ground55 cmReference
Track area on ground0.1 m²Reference
Ground pressure0.0 barReference
Sno-Cub Serial Number Location
Serial number decal inside the hood on the right side.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
