Tractor · 2008Unverified
Zetor 12050
Zetor 12050 — Silver Series · 120 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
120 hp
Weight
4102 kg
Hover a source tag to verify
Overview
ManufacturerZetorReference
Built in Brno, Czech RepublicReference
Four-wheel driveReference
Differential lockmechanical rearReference
Differential locklimited-slip frontReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-condtioning.Reference
Engine
Zetor 4.2L 4-cyl dieselReference
Fuel tank181.7 LReference
Engine (gross)89.5 kWReference
Engine (net)85.0 kWReference
ZetorReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
Power (net)85.0 kWReference
Power (gross)89.5 kWReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speed three-speed power shiftReference
Typethree-speed power shiftReference
Gears24 forward and reverseReference
Clutchwet discReference
Synchronized transmission with three-speed push-button power shift and power shuttle. Electric declutch button.Reference
PTO & Hydraulics
PTO (claimed)77.6 kWReference
Typeopen centerReference
Pressure200.0 barReference
Valves3Reference
SCV flow53.0 lpmReference
Total flow75.7 lpmReference
Steering flow22.7 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift (at ends)3447 kgReference
Rear lift (at ends)4150 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase243 cmReference
Weight4102 kgReference
Front tire13.6R24Reference
Rear tire18.4R34Reference
Standard tires (ag)Front: 13.6R24. Rear: 18.4R34Reference
Length398 cmReference
Width198 cmReference
Height (cab)269 cmReference
Ground clearance45 cmReference
Front tread149 to 195 cmReference
Rear tread149 to 180 cmReference
Zetor 12050 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps95Reference
Charging volts12Reference
Battery CCA950Reference
Battery volts12Reference
Attachment overview
Zetor 120K loaderReference
Zetor 120SLi loaderReference
Speeds
With 18.4R34 rear tires. Reverse speeds are 6% faster than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
