Tractor · 1948Unverified
Zetor 25K
Zetor 25K — Row-Crop tractor · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
1955 kg
Hover a source tag to verify
Overview
ManufacturerZetorReference
Row-Crop tractorReference
Built in Brno, CzechoslovakiaReference
Two-wheel driveReference
Open operator station.Reference
Variants
25Astandard chassisReference
25Krow-crop chassisReference
Engine
Zetor 2.1L 2-cyl dieselReference
Fuel tank45.0 LReference
Engine18.6 kWReference
ZetorReference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement2.1 LReference
Bore/Stroke105 x 120 mmReference
Power18.6 kWReference
Compression18:1Reference
Rated RPM1800Reference
Starter volts12Reference
Starter power3.0 kWReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear PTOliveReference
Rear PTO Type540Reference
Engine RPM535@1600Reference
Dimensions
Wheelbase189 cmReference
Weight1955 kgReference
Front tire5.50-16Reference
Rear tire9-36Reference
Ag front5.50-16Reference
Ag rear9-36Reference
Ag rear13-28Reference
Length320 cmReference
Clearance (front axle)52 cmReference
Front tread122 to 151 cmReference
Electrical
GroundnegativeReference
Charging systemgeneratorReference
Charging amps12.5Reference
Battery volts12Reference
Battery AH150Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
