Tractor · 1997Unverified
Zetor 3321
Zetor 3321 — Range 1 Super Series · 43 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
43 hp
Weight
2821 kg
Hover a source tag to verify
Overview
ManufacturerZetorReference
Utility tractorReference
Built in Brno, Czech RepublicReference
Two-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Variants
33212WDReference
33414WDReference
Engine
Zetor 2.7L 3-cyl dieselReference
Fuel tank121.1 LReference
Engine34.3 kWReference
ZetorReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke102 x 110 mmReference
Power34.3 kWReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
10-speed synchronizedReference
10-speed mechanical shuttleReference
TypesynchronizedReference
Gears10 forward and 2 reverseReference
Clutchhydraulic 304.8mm cerametallic discReference
Typemechanical shuttleReference
Gears10 forward and reverseReference
PTO & Hydraulics
PTO (claimed)32.1 kWReference
Typeopen centerReference
Pressure179.3 barReference
Valves1 to 3Reference
Pump flow53.0 lpmReference
Steering flow15.1 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift1950 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase185 cmReference
Weight2821 kgReference
Front tire6.50-16Reference
Rear tire16.9-28Reference
Ag front6.50-16Reference
Ag rear16.9-28Reference
Length337 cmReference
Width185 cmReference
Height (cab)256 cmReference
Ground clearance48 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps75Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
