Tractor · 1995Unverified
Zetor 3520
Zetor 3520 · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
1723 kg
Hover a source tag to verify
Overview
ManufacturerZetorReference
Built in Brno, Czech RepublicReference
Original price$9500 (1995)Reference
Engine
Zetor 2.3L 3-cyl dieselReference
ZetorReference
dieselReference
3-cylinderReference
Displacement2.3 LReference
Transmission
10-speedReference
Gears10 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)26.1 kWReference
TypeopenReference
Pump flow20.1 lpmReference
Rear TypeIReference
Rear lift997 kgReference
Rear PTOliveReference
Rear PTO Type540Reference
Dimensions
Weight1723 kgReference
Front tire5.50-16Reference
Rear tire12.4-28Reference
Ag front5.50-16Reference
Ag rear12.4-28Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
