The Zetor 4016 is a compact tractor with a rated output of 53 hp, featuring a 4-cylinder diesel engine. It was manufactured from 1962 to 1967 and is equipped with a 10-speed gearbox driving a tracked undercarriage. The tractor's listed weight is 1964 kg, making it suitable for jobs covering approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
53 hp
Weight
1964 kg
Catalogue coverage
Variants represented
2
Richest spec table
29 rows
Recorded power
53 hp
Recorded weight
1964 kg
Transmissions
10-speed
Production years
1962-1967
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerZetorReference
Half-track Crawler tractorReference
Built in Brno, CzechoslovakiaReference
Drivehalf-trackReference
Engine
Zetor 3.1L 4-cyl dieselReference
Engine39.5 kWReference
ZetorReference
dieselReference
4-cylinderReference
Displacement3.1 LReference
Bore/Stroke95 x 110 mmReference
Power39.5 kWReference
Rated RPM2000Reference
Transmission
10-speedReference
Gears10 forward and 2 reverseReference
PTO & Hydraulics
Rear TypeIIReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
Wheelbase212 cmReference
Weight1964 kgReference
Front tire5.50-16Reference
Rear tiretracksReference
Ag front5.50-16Reference
Ag reartracksReference
Length325 cmReference
Width213 cmReference
Height162 cmReference
Front tread134 cmReference
Rear tread157 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
