Tractor · 1993Unverified

Zetor 4320

Name: Zetor 4320
Brand: Zetor

Zetor 4320 — Range 1 Series · 53 hp. Reference specifications; pending source verification.

The Zetor 4320 is a tractor with an approximate power output of 53 hp, categorising it as a lighter model within its class. Produced from 1993 to 1997, this tractor features a 4-cylinder diesel liquid-cooled engine and four-wheel drive, coupled with a 10-speed gearbox. It has a listed operating weight of 2948 kg and is designed for use in areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

53 hp

Max power

34.8 kW

Weight

2948 kg

Catalogue coverage

Variants represented

Richest spec table

74 rows

Recorded power

53 hp

Recorded weight

2948 kg

Transmissions

10-speed synchro

Production years

1993-1997

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerZetorReference

Utility tractorReference

Built in Brno, Czech RepublicReference

Original price was $18,500 in 1998Reference

Two-wheel driveReference

Power steeringReference

Hydraulic dry disc brakesReference

Two-post ROPS. Cab available with air-conditioning.Reference

Variants

43202WDReference

43404WDReference

Engine

Zetor 3.5L 4-cyl dieselReference

Fuel tank70.0 LReference

Engine44.0 kWReference

Drawbar (tested)34.8 kWReference

Zetor Z6201Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.5 LReference

Bore/Stroke100 x 110 mmReference

Power44.0 kWReference

Compression17:1Reference

Rated RPM2200Reference

Starter volts12Reference

Coolant capacity13.7 LReference

Power at rated engine speed39.6 kWReference

Max power34.8 kWReference

Transmission

10-speed synchroReference

10-speedReference

TypesynchroReference

Gears10 forward and 2 reverseReference

Clutchhydraulic 304.8mm cerametallic discReference

Transmissionmechanical shuttleReference

Gears10 forward and reverseReference

PTO & Hydraulics

PTO (claimed)41.0 kWReference

PTO (tested)39.6 kWReference

Typeopen centerReference

Pressure179.3 barReference

Valves1 to 3Reference

Pump flow41.6 lpmReference

Total flow56.8 lpmReference

Steering flow15.1 lpmReference

Rear TypeII/IReference

Controlposition and draft controlReference

Rear lift2653 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000 (1.375)Reference

Power at rated PTO speed37.5 kWReference

Dimensions

Wheelbase223 cmReference

Weight2948 kgReference

Front tire9.00-16Reference

Rear tire16.9-28Reference

Ag front9.00-16Reference

Ag rear16.9-28Reference

Length355 cmReference

Width185 cmReference

Height (steering wheel)182 cmReference

Height (cab)256 cmReference

Ground clearance53 cmReference

Zetor 4320 attachments

front-end loaderReference

Electrical

Charging systemalternatorReference

Charging amps55Reference

Battery CCA950Reference

Battery volts12Reference

Test results

Diesel 10-speed 4WDSeptember 11 - 30, 1986Link: Nebraska Tractor Test 1601 fileReference

PTO performanceReference

Fuel use12.9 l/hourReference

Fuel use11.7 l/hourReference

Drawbar performanceReference

Gear 2H used for power test.Reference

Max pull2872 kgReference

Gear 4L used for pull test.Reference

Speeds

With 16.9-28 rear tires.Reference

With 16.9-28 rear tires. Reverse speeds are 10% faster than forward.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
