Tractor · 1993Unverified
Zetor 4340
Zetor 4340 — Range 1 Series · 53 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
53 hp
Max power
34.8 kW
Weight
3388 kg
Hover a source tag to verify
Overview
ManufacturerZetorReference
Utility tractorReference
Built in Brno, Czech RepublicReference
Original price was $22,000 in 1998Reference
Four-wheel driveReference
Power steeringReference
Hydraulic dry disc brakesReference
Two-post ROPS. Cab available with air-conditioning.Reference
Variants
43202WDReference
43404WDReference
Engine
Zetor 3.5L 4-cyl dieselReference
Fuel tank70.0 LReference
Engine44.0 kWReference
Drawbar (tested)34.8 kWReference
Zetor Z6201Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.5 LReference
Bore/Stroke100 x 110 mmReference
Power44.0 kWReference
Compression17:1Reference
Rated RPM2200Reference
Starter volts12Reference
Coolant capacity13.7 LReference
Power at rated engine speed39.6 kWReference
Max power34.8 kWReference
Transmission
10-speed synchroReference
10-speedReference
TypesynchroReference
Gears10 forward and 2 reverseReference
Clutchhydraulic 304.8mm cerametallic discReference
Transmissionmechanical shuttleReference
Gears10 forward and reverseReference
PTO & Hydraulics
PTO (claimed)41.0 kWReference
PTO (tested)39.6 kWReference
Typeopen centerReference
Pressure179.3 barReference
Valves1 to 3Reference
Pump flow41.6 lpmReference
Total flow56.8 lpmReference
Steering flow15.1 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift2653 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Power at rated PTO speed37.5 kWReference
Dimensions
Wheelbase223 cmReference
Weight3388 kgReference
Front tire11.2/24Reference
Rear tire16.9-28Reference
Ag front11.2/24Reference
Ag rear16.9-28Reference
Length355 cmReference
Width185 cmReference
Height (steering wheel)185 cmReference
Height (cab)259 cmReference
Ground clearance40 cmReference
Zetor 4340 attachments
front-end loaderReference
Electrical
Charging systemalternatorReference
Charging amps55Reference
Battery CCA950Reference
Battery volts12Reference
Test results
Diesel 10-speed 4WDSeptember 11 - 30, 1986Link: Nebraska Tractor Test 1601 fileReference
PTO performanceReference
Fuel use12.9 l/hourReference
Fuel use11.7 l/hourReference
Drawbar performanceReference
Gear 2H used for power test.Reference
Max pull2872 kgReference
Gear 4L used for pull test.Reference
Speeds
With 16.9-28 rear tires.Reference
With 16.9-28 rear tires. Reverse speeds are 10% faster than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
