Tractor · 1972Unverified
Zetor 4712
Zetor 4712 — UR1 7 Series · 42 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
42 hp
Weight
2049 kg
Hover a source tag to verify
Overview
ManufacturerZetorReference
Built in Brno, CzechoslovakiaReference
Two-wheel driveReference
Differential hydraulic drum brakesReference
Trailer brakesair optionalReference
Open operator station.Reference
Variants
4712open-stationReference
4718cabReference
Engine
Zetor 2.6L 3-cyl dieselReference
Fuel tank46.9 LReference
Engine33.6 kWReference
Zetor Z4701Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.6 LReference
Bore/Stroke100 x 110 mmReference
Power33.6 kWReference
Compression17.9:1Reference
Rated RPM2200Reference
Transmission
10-speedReference
Gears10 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)31.3 kWReference
TypeZetormaticReference
Pressure160.0 barReference
Valves1Reference
Pump flow20.1 lpmReference
Rear lift1200 kgReference
Rear PTOindependentReference
Rear PTO Type540/groundReference
Rear PTO Type1000Reference
Dimensions
Wheelbase198 cmReference
Weight2049 kgReference
Front tire6.00-16Reference
Rear tire12.4-32Reference
Ag front6.00-16Reference
Ag rear12.4-32Reference
Rear tread128 to 180 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
