Tractor · 1985Unverified
Zetor 5211
Zetor 5211 — Row-Crop tractor · 43 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
43 hp
Max power
28.3 kW
Weight
5160 to 5910 pounds
Hover a source tag to verify
Overview
ManufacturerZetorReference
Row-Crop tractorReference
Built in Brno, CzechoslovakiaReference
Original price was $12,000 in 1992Reference
Two-wheel driveReference
Differential lockmechanical rearReference
Open operator station.Reference
Variants
52112WDReference
52454WDReference
5211Olow-profileReference
Engine
Zetor 2.7L 3-cyl dieselReference
Fuel tank54.9 LReference
Engine34.2 kWReference
Drawbar (claimed)28.3 kWReference
Drawbar (tested)28.3 kWReference
Zetor 5201Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke102 x 110 mmReference
Power34.2 kWReference
Fuel systemdirect injectionReference
Rated RPM2200Reference
Idle RPM600-2400Reference
Firing order1-3-2Reference
StarterelectricReference
Starter volts12Reference
Oil capacity9.0 LReference
Coolant capacity8.0 LReference
Coolant capacity10.5 LReference
Intake valve clearance0.254 mmReference
Exhaust valve clearance0.254 mmReference
Power at rated engine speed31.7 kWReference
Max power28.3 kWReference
Transmission
10-speed gearReference
TypegearReference
Gears10 forward and 2 reverseReference
Oil capacity32.0 LReference
Five gears, plus reverse, in two ranges.Reference
PTO & Hydraulics
PTO (claimed)31.7 kWReference
PTO (tested)31.7 kWReference
Typeopen centerReference
Valves2Reference
Pump flow30.3 lpmReference
Rear TypeII/IReference
Rear lift (at ends)1782 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Power at rated PTO speed29.9 kWReference
Dimensions
Wheelbase212 cmReference
Weight5160 to 5910 poundsReference
Front tire6.00-16Reference
Rear tire12.4-28Reference
Ag front6.00-16Reference
Ag rear12.4-28Reference
Ag front6.50-16Reference
Ag front7.50-16Reference
Ag rear14.9-28Reference
Ag rear9.5-32Reference
Ag rear12.4-32Reference
Ag rear12.4-36Reference
Ag rear13.6-36Reference
Length363 cmReference
Width180 cmReference
Weight2680 kgReference
5211O Weight2340 kgReference
Clearance (front axle)46 cmReference
Rear tread134 to 180 cmReference
Steering wheel175 cmReference
5211O Steering wheel156 cmReference
5211 Serial Numbers
Location:Serial number plate on the right side of the dashboard.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Zetor 5211 Height
Exhaust231 cmReference
Test results
Diesel 10-speed 4WDAugust 22 - September 5, 1985Link: Nebraska Tractor Test 1571 fileReference
PTO performanceReference
Fuel use10.2 l/hourReference
Drawbar performanceReference
Fuel use9.8 l/hourReference
Gear 3H used for power test.Reference
Max pull2701 kgReference
Gear 4L used for pull test.Reference
Speeds
With 12.4-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
