Tractor · 1968Unverified

Zetor 5516

Name: Zetor 5516
Brand: Zetor

Zetor 5516 — Half-track Crawler tractor · 60 hp. Reference specifications; pending source verification.

The Zetor 5516 is a tractor with a rated power output of 60 hp, categorising it as a lighter model within its class. Manufactured between 1968 and 1972, this model is equipped with a 4-cylinder diesel liquid-cooled engine and a tracked undercarriage featuring a 10-speed gearbox. The Zetor 5516 has an operating weight of 2439 kg and is suited to operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

60 hp

Weight

2439 kg

Catalogue coverage

Variants represented

Richest spec table

27 rows

Recorded power

60 hp

Recorded weight

2439 kg

Transmissions

10-speed

Production years

1968-1972

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerZetorReference

Half-track Crawler tractorReference

Built in Brno, CzechoslovakiaReference

Drivehalf-trackReference

Open operator station.Reference

Engine

Zetor 3.1L 4-cyl dieselReference

Engine44.7 kWReference

ZetorReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.1 LReference

Bore/Stroke95 x 110 mmReference

Power44.7 kWReference

Rated RPM2200Reference

Transmission

10-speedReference

Gears10 forward and 2 reverseReference

PTO & Hydraulics

Rear TypeIIReference

Rear lift1630 kgReference

Rear PTOindependentReference

Rear PTO Type540,1000Reference

Dimensions

Wheelbase226 cmReference

Weight2439 kgReference

Front tire6.00-20Reference

Rear tiretracksReference

Ag front6.00-20Reference

Ag reartracksReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
