Tractor · 1972Unverified
Zetor 5745
Zetor 5745 — UR1 7 Series · 54 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
54 hp
Weight
2621 kg
Hover a source tag to verify
Overview
ManufacturerZetorReference
Built in Brno, CzechoslovakiaReference
Four-wheel driveReference
Differential hydraulic drum brakesReference
Trailer brakespneumatic optionalReference
Open operator station.Reference
Variants
57112WDReference
57182WD cabReference
57454WDReference
57484WD cabReference
Engine
Zetor 3.1L 4-cyl dieselReference
Fuel tank70.0 LReference
Engine43.3 kWReference
Zetor Z5701Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.1 LReference
Bore/Stroke95 x 110 mmReference
Power43.3 kWReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
10-speedReference
20-speed partial power shiftReference
Gears10 forward and 2 reverseReference
Typepartial power shiftReference
Gears20 forward and 4 reverseReference
The optional multi-power transmission provided a two-speed power shift between direct drive and a lower range.Reference
PTO & Hydraulics
PTO (claimed)40.3 kWReference
TypeZetormaticReference
Pressure160.0 barReference
Valves1Reference
Pump flow20.1 lpmReference
Rear TypeIIReference
Rear lift (at ends)1746 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@2000Reference
Engine RPM1000@2050Reference
Dimensions
Wheelbase223 cmReference
Weight2621 kgReference
Front tire9.5-24Reference
Rear tire12.4-36Reference
Standard tires (ag)Front: 9.5-24. Rear: 12.4-36Reference
Length347 cmReference
Width182 cmReference
Height (steering wheel)162 cmReference
Ground clearance33 cmReference
Front tread147 cmReference
Rear tread142 to 177 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
