Tractor · 2008Unverified
Zetor 7040
Zetor 7040 — Silver Series · 70 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
70 hp
Weight
7690 to 8190 pounds
Hover a source tag to verify
Overview
ManufacturerZetorReference
Built in Brno, Czech RepublicReference
Four-wheel driveReference
Differential lockmechanical rearReference
Differential locklimited-slip frontReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Variants
70202WDReference
70404WDReference
Engine
Zetor 4.2L 4-cyl dieselReference
ROPS Fuel tank83.3 LReference
Cab Fuel tank128.7 LReference
Engine (gross)52.2 kWReference
Engine (net)50.0 kWReference
ZetorReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
Power (net)50.0 kWReference
Power (gross)52.2 kWReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed synchronizedReference
TypesynchronizedReference
Gears12 forward and reverseReference
Clutch304.8mm hydraulic cerametallic discReference
Synchronized transmission with mechanical shuttle.Reference
PTO & Hydraulics
PTO (claimed)47.0 kWReference
Typeopen centerReference
Pressure200.0 barReference
Valves1 to 3Reference
SCV flow53.0 lpmReference
SCV flow64.3 lpmReference
Total flow75.7 lpmReference
Steering flow22.7 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
ROPS Rear lift (at ends)2358 kgReference
Cab Rear lift (at ends)3447 kgReference
Rear PTOindependentReference
ClutchmechanicalReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase226 cmReference
Weight7690 to 8190 poundsReference
Front tire11.2-24Reference
Rear tire16.9-30Reference
Standard tires (ag)Front: 11.2-24. Rear: 16.9-30Reference
Length386 cmReference
Width185 cmReference
Height (ROPS)261 cmReference
Height (cab)261 cmReference
ROPS Weight3488 kgReference
Cab Weight3714 kgReference
Ground clearance40 cmReference
Front tread149 to 195 cmReference
Rear tread142 to 180 cmReference
Zetor 7040 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
ROPS Charging amps55Reference
Cab Charging amps95Reference
Charging volts12Reference
Battery CCA950Reference
Battery volts12Reference
Attachment overview
Zetor 120K loaderReference
Zetor 120SLi loaderReference
Speeds
With 16.9-34 rear tires. Reverse speeds are 9% faster than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
