Tractor · 1995Unverified
Zetor 7520
Zetor 7520 — Range 3 Series · 63 hp. Reference specifications; pending source verification.
The Zetor 7520 is a compact tractor, rated at 63 hp, which places it in a category of smaller machines. It was produced from 1995 to 1999, and features a 4-cylinder diesel liquid-cooled engine powering a four-wheel drive system with a hydrostatic transmission. The listed weight for this model is 3329 kg, and it is designed for use on areas of approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
63 hp
Weight
3329 kg
Catalogue coverage
Variants represented
2
Richest spec table
55 rows
Recorded power
63 hp
Recorded weight
3329 kg
Transmissions
16-speed
Production years
1995-1999
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerZetorReference
Built in Brno, Czech RepublicReference
Original price was $34,000 in 1995Reference
Two-wheel driveReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Cab standard with heater.Reference
Variants
75202WDReference
75404WDReference
Engine
Zetor 4.2L 4-cyl dieselReference
Engine52.9 kWReference
Zetor Z 7801Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
Power52.9 kWReference
Rated RPM2200Reference
Starter volts12Reference
Starter power3.4 kWReference
Transmission
16-speedReference
18-speed synchromeshReference
Gears16 forward and 4 reverseReference
TypesynchromeshReference
Gears18 forward and 6 reverseReference
Three gears in high/low/reverse ranges with a three-speed torque multiplier.Reference
PTO & Hydraulics
PTO (claimed)47.0 kWReference
TypeopenReference
Pressure184.9 barReference
Valves3Reference
Total flow60.0 lpmReference
Rear TypeIIReference
Rear lift3250 kgReference
Front HitchoptionalReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase237 cmReference
Weight3329 kgReference
Front tire7.50-20Reference
Rear tire16.9-34Reference
Ag front7.50-20Reference
Ag rear16.9-34Reference
Ag rear13.6-38Reference
Length389 cmReference
Width192 cmReference
Height (cab)264 cmReference
Height (exhaust)277 cmReference
Ground clearance37 cmReference
Rear tread150 to 180 cmReference
Electrical
Charging systemalternatorReference
Charging amps55Reference
Charging volts12Reference
Battery volts12Reference
Speeds
With 16.9x38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
