Tractor · 2008Unverified
Zetor 9020
Zetor 9020 — Silver Series · 93 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
93 hp
Weight
7090 to 7590 pounds
Hover a source tag to verify
Overview
ManufacturerZetorReference
Built in Brno, Czech RepublicReference
Two-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Variants
90202WDReference
90404WDReference
Engine
Zetor 4.2L 4-cyl dieselReference
ROPS Fuel tank83.3 LReference
Cab Fuel tank151.4 LReference
Engine (gross)69.4 kWReference
Engine (net)64.9 kWReference
ZetorReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
Power (net)64.9 kWReference
Power (gross)69.4 kWReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed synchronizedReference
TypesynchronizedReference
Gears12 forward and reverseReference
Clutch304.8mm hydraulic cerametallic discReference
Synchronized transmission with mechanical shuttle.Reference
PTO & Hydraulics
PTO (claimed)60.4 kWReference
Typeopen centerReference
Pressure200.0 barReference
Valves1 to 3Reference
SCV flow53.0 lpmReference
SCV flow64.3 lpmReference
Total flow75.7 lpmReference
Steering flow22.7 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift (at ends)3447 kgReference
Rear lift (at ends)4150 kgReference
Rear PTOindependentReference
ClutchmechanicalReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase231 cmReference
Weight7090 to 7590 poundsReference
Front tire9.00-16Reference
Rear tire16.9-34Reference
Standard tires (ag)Front: 9.00-16. Rear: 16.9-34Reference
Length386 cmReference
Width185 cmReference
Height (ROPS)266 cmReference
Height (cab)266 cmReference
ROPS Weight3216 kgReference
Cab Weight3442 kgReference
Ground clearance55 cmReference
Front tread142 to 190 cmReference
Rear tread142 to 180 cmReference
Zetor 9020 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
ROPS Charging amps55Reference
Cab Charging amps95Reference
Charging volts12Reference
Battery CCA950Reference
Battery volts12Reference
Attachment overview
Zetor 120K loaderReference
Zetor 120SLi loaderReference
Speeds
With 16.9-34 rear tires. Reverse speeds are 9% faster than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
