Tractor · 2008Unverified

Zetor 9050

Name: Zetor 9050
Brand: Zetor

Zetor 9050 — Silver Series · 93 hp. Reference specifications; pending source verification.

The Zetor 9050 is a tractor with a rated power output of 93 hp, a mid-range figure for its class. It was manufactured from 2008 to 2011 and features a 4-cylinder turbocharged diesel liquid-cooled engine paired with four-wheel drive and a powershift transmission. The tractor has an operating weight of 8550 to 8980 pounds and is suited for operations covering 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

93 hp

Max power

93 hp

Weight

8550 to 8980 pounds

Catalogue coverage

Variants represented

Richest spec table

111 rows

Recorded power

93 hp

Recorded weight

3878 kg

Transmissions

16-speed two-speed power shift

Production years

2008-2011

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerZetorReference

Built in Brno, Czech RepublicReference

Four-wheel driveReference

Differential lockmechanical rearReference

Differential locklimited-slip frontReference

Power steeringReference

Hydraulic wet disc brakesReference

Cab standard with air-condtioning.Reference

Engine

Zetor 4.2L 4-cyl dieselReference

Mech shuttle Fuel tank151.4 LReference

Power shuttle Fuel tank181.7 LReference

Engine (gross)69.4 kWReference

Engine (net)66.4 kWReference

Power shuttle Wheelbase243 cmReference

Power shuttle Length398 cmReference

Power shuttle Weight4073 kgReference

ZetorReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.2 LReference

Bore/Stroke105 x 120 mmReference

Power (net)66.4 kWReference

Power (gross)69.4 kWReference

Rated RPM2200Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders4 cylinderReference

Rated engine speed2,200 RPMReference

Bore and stroke4.13x4.72 inchesReference

Cooling systemliquid-cooledReference

Transmission

16-speed two-speed power shiftReference

24-speed three-speed power shiftReference

Typetwo-speed power shiftReference

Gears16 forward and reverseReference

Clutch304.8mm hydraulic cerametallic discReference

Synchronized transmission with two-speed push-button power shift and synchronized shuttle.Reference

Typethree-speed power shiftReference

Gears24 forward and reverseReference

Clutchwet discReference

Synchronized transmission with three-speed push-button power shift and power shuttle. Electric declutch button.Reference

Transmission TypePowershiftReference

Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)61.9 kWReference

Typeopen centerReference

Pressure200.0 barReference

Valves3Reference

SCV flow53.0 lpmReference

Total flow75.7 lpmReference

Steering flow22.7 lpmReference

Rear TypeII/IReference

Controlposition and draft controlReference

Rear lift (at ends)3447 kgReference

Rear lift (at ends)4150 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulic wet discReference

Rear PTO Type540/1000 (1.375)Reference

Dimensions

Mech shuttle Wheelbase233 cmReference

Weight8550 to 8980 poundsReference

Front tire13.6R24Reference

Rear tire18.4R34Reference

Standard tires (ag)Front: 13.6R24. Rear: 18.4R34Reference

Mech shuttle Length388 cmReference

Width198 cmReference

Height (cab)269 cmReference

Mech shuttle Weight3878 kgReference

Ground clearance45 cmReference

Front tread149 to 195 cmReference

Rear tread149 to 180 cmReference

Zetor 9050 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps95Reference

Charging volts12Reference

Battery CCA950Reference

Battery volts12Reference

Total cold cranking amps950 CCAReference

Attachment overview

Zetor 120K loaderReference

Zetor 120SLi loaderReference

Speeds

With 18.4R34 rear tires. Reverse speeds are 6% faster than forward.Reference

General

Make & ModelZetorReference

SCV controlJoystickReference

Country of manufacturerBrno, Czech RepublicReference

Capacities

Capacity254 ciReference

Fuel tank181.7 LReference

Power

Max Power93 hpReference

Rated Power89 hpReference

PTO

PTO Power83 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Steering & brakes

Brakeshydraulic wet discReference

Steering typepowerReference

Hydraulics

Pump Rated Output (total)20 gpmReference

Hydraulics Typeopen centerReference

Maximum operating pressure2,900 psiReference

Remote Valves3 ValvesReference

Steering & Implements flow6 gpmReference

Rear Hitch category (SAE designation)Category II/IReference

Rear Hitch maximum lift capacity4,150.4 kgReference

Rear Hitch Sensing Typeposition and draft controlReference

Dimensions & weight

Wheelbase243.8 cmReference

Height Over Cab269.2 cmReference

Overall Length398.8 cmReference

Overall Width198.1 cmReference

Overall weight4,073.3 kgReference

Wheels & tyres

Rear Wheel TypeAg rear - 18.4R34Reference

Rear wheel tread range59 to 71 inchesReference

Front Wheel TypeAg front - 13.6R24.Reference

Front Wheel tread range59 to 77 inchesReference

Operator station

Cab AvailabilityAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
