Tractor · 1990Unverified
Zetor 9245
Zetor 9245 — Row-Crop tractor · 80 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
80 hp
Weight
4369 kg
Hover a source tag to verify
Overview
ManufacturerZetorReference
Row-Crop tractorReference
Built in Brno, CzechoslovakiaReference
Four-wheel driveReference
Power steeringReference
Hydraulic dry disc brakesReference
Trailer brakeshydraulicReference
Cab standard with heater.Reference
Variants
92112WDReference
92454WDReference
Engine
Zetor 4.6L 4-cyl dieselReference
Fuel tank124.9 LReference
Engine67.1 kWReference
Zetor Z 8002.13Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.6 LReference
Bore/Stroke110 x 120 mmReference
Power67.1 kWReference
Fuel systemdirect injectionReference
Rated RPM2200Reference
Starter typeelectricReference
Transmission
16-speed synchromeshReference
TypesynchromeshReference
Gears16 forward and 8 reverseReference
Clutch350mm hydraulic dry discReference
Four gears (1-4) in two ranges (low/high) plus reverse range, with two-speed torque multiplier.Reference
PTO & Hydraulics
PTO (claimed)59.7 kWReference
Typeopen centerReference
Pressure188.2 barReference
Valves2Reference
Total flow46.9 lpmReference
Rear TypeIIReference
Rear lift3463 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Weight4369 kgReference
Front tire12.4x24Reference
Rear tire16.9x38Reference
Standard tires (ag)Front: 12.4x24. Rear: 16.9x38Reference
Length398 cmReference
Width195 cmReference
Height (cab)271 cmReference
Height (exhaust)288 cmReference
Ballasted weight5100 kgReference
Ground clearance38 cmReference
Rear tread150 to 187 cmReference
Electrical
Charging systemalternatorReference
Charging amps55Reference
Speeds
With 16.9x38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
