Tractor · 2020Unverified
Zetor Compax 25
Zetor Compax 25 — Compax Series · 23 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
23 hp
Hover a source tag to verify
Overview
DistributorZetorReference
ManufacturerTYMReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Two-post folding ROPS.Reference
Variants
CL 25gearReference
HT 25hydrostaticReference
Engine
Yanmar dieselReference
Fuel tank22.0 LReference
Engine (gross)17.4 kWReference
YanmarReference
dieselReference
liquid-cooledReference
EmissionsStage 5Reference
Rated Power (gross)17.4 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed sync shuttleReference
hydrostaticReference
Typesync shuttleReference
Gears6 forward and 2 reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
Rear valves2Reference
Pump flow26.5 lpmReference
Rear TypeINReference
Controlposition controlReference
Rear lift600 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Dimensions
Wheelbase146 cmReference
Front tire6.0-12Reference
Rear tire9.5-16Reference
Standard tires (ag)Front: 6.0-12. Rear: 9.5-16Reference
Industrial front20x8.0-10Reference
Industrial rear27x12.5-15Reference
Length255 cmReference
Width116 cmReference
Height (ROPS)231 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
