Tractor · 2020Unverified
Zetor Compax 35
Zetor Compax 35 — Compax Series · 34 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
34 hp
Hover a source tag to verify
Overview
DistributorZetorReference
ManufacturerTYMReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Two-post folding ROPS. Cab optional.Reference
Variants
CL 35gearReference
HT 35hydrostaticReference
Engine
Yanmar dieselReference
Fuel tank34.1 LReference
Engine (gross)25.5 kWReference
YanmarReference
dieselReference
liquid-cooledReference
EmissionsStage 5Reference
Rated Power (gross)25.5 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed sync shuttleReference
hydrostaticReference
ROPS gear Wheelbase164 cmReference
Cab gear Wheelbase169 cmReference
Typesync shuttleReference
Gears12 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Rear valves2Reference
Mid valves2Reference
Gear Pump flow40.1 lpmReference
Hydro Pump flow41.3 lpmReference
Rear TypeIReference
Controlposition controlReference
Controldraft controlReference
Rear lift1200 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Dimensions
Hydro Wheelbase167 cmReference
Front tire8.0-16Reference
Rear tire12.4-24Reference
Standard tires (ag)Front: 8.0-16. Rear: 12.4-24Reference
Lawn/turf front27x10.5-15Reference
Lawn/turf rear41x14-20Reference
Industrial front27x10.5-15Reference
Industrial rear12.5-20Reference
ROPS Length320 cmReference
Cab Length325 cmReference
ROPS Width135 cmReference
Cab Width147 cmReference
Height (ROPS)240 cmReference
Height (cab)234 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
