Tractor · 1999Unverified
Zetor Forterra 11641
Zetor Forterra 11641 — Forterra Series · 110 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
110 hp
Weight
4450 kg
Hover a source tag to verify
Overview
ManufacturerZetorReference
Built in Brno, CzechoslovakiaReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with available air-conditioning.Reference
Engine
SAME 6.0L 6-cyl dieselReference
Fuel tank180.2 LReference
Engine82.0 kWReference
SAME 1006.6WReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.0 LReference
Bore/Stroke105 x 116 mmReference
Power82.0 kWReference
Rated RPM2350Reference
Torque390.0 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speed synchronizedReference
TypesynchronizedReference
Gears24 forward and 18 reverseReference
Clutchhydraulic dry discReference
PTO & Hydraulics
Pump flow70.0 lpmReference
Rear lift5800 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase264 cmReference
Weight4450 kgReference
Front tire420/70R24Reference
Rear tire520/70R38Reference
Standard tires (ag)Front: 420/70R24. Rear: 520/70R38Reference
Length464 cmReference
Height271 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
