Tractor · 2012Unverified
Zetor Forterra 140 HD
Zetor Forterra 140 HD — Model year 2012-20162016-2025 · 136 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
136 hp
Weight
4819 kg
Hover a source tag to verify
Overview
ManufacturerZetorReference
Built in Brno, Czech RepublicReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Zetor 4.2L 4-cyl dieselReference
Fuel tank219.9 LReference
Engine101.4 kWReference
Zetor Z 1606Reference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
Power101.4 kWReference
Rated RPM2200Reference
Torque581.0 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
30-speedReference
Gears30 forward and reverseReference
PTO & Hydraulics
Pressure200.0 barReference
Pump flow85.2 lpmReference
Pump flow120.0 lpmReference
Rear lift8500 kgReference
Rear PTO Type540/750/1000/1250Reference
Dimensions
Wheelbase272 cmReference
Weight4819 kgReference
Front tire480/65R24Reference
Rear tire600/65R38Reference
Ag front480/65R24Reference
Ag rear600/65R38Reference
Length477 cmReference
Height (cab)283 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
