Tractor · 2020Unverified
Zetor M22
Zetor M22 — M Compact Series · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Hover a source tag to verify
Overview
ManufacturerZetorReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Two-post folding ROPS.Reference
Engine
Yanmar 3-cyl dieselReference
Engine16.4 kWReference
YanmarReference
dieselReference
3-cylinderReference
liquid-cooledReference
Power16.4 kWReference
Starter typeelectricReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
PTO (claimed)13.1 kWReference
Pump flow26.4 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift498 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type2500Reference
Zetor M22 attachments
54" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Attachment overview
54" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
54" Mower deck
Typemid-mount ZetorReference
Type3-bladeReference
Cutting width137 cmReference
Zetor ZB70 Backhoe
Backhoe typeZetor ZB70 BackhoeReference
Digging depth195 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
