Tractor · 2020Unverified

Zetor M22

Name: Zetor M22
Brand: Zetor

Zetor M22 — M Compact Series · 18 hp. Reference specifications; pending source verification.

The Zetor M22 is a tractor model rated at 18 hp — making it one of the more compact options in its class. It was manufactured in 2020. Under the hood is a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a hydrostatic transmission. It is aimed at jobs of around up to 200 ac. The available specification table below shows both UK and US units.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

18 hp

Catalogue coverage

Variants represented

Richest spec table

37 rows

Recorded power

18 hp

Transmissions

hydrostatic

Production years

2020-2020

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerZetorReference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Two-post folding ROPS.Reference

Engine

Yanmar 3-cyl dieselReference

Engine16.4 kWReference

YanmarReference

dieselReference

3-cylinderReference

liquid-cooledReference

Power16.4 kWReference

Starter typeelectricReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

PTO & Hydraulics

PTO (claimed)13.1 kWReference

Pump flow26.4 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift498 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540 (1.375)Reference

Mid PTOindependentReference

Mid PTO Type2500Reference

Zetor M22 attachments

54" mid-mount mower deckReference

front-end loaderReference

backhoeReference

Attachment overview

54" mid-mount mower deckReference

Front-end loaderReference

BackhoeReference

54" Mower deck

Typemid-mount ZetorReference

Type3-bladeReference

Cutting width137 cmReference

Zetor ZB70 Backhoe

Backhoe typeZetor ZB70 BackhoeReference

Digging depth195 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
