Tractor · 2020Unverified
Zetor M70
Zetor M70 — M Compact Series · 73 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
73 hp
Hover a source tag to verify
Overview
ManufacturerZetorReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Cab standard.Reference
Engine
Deutz 4-cyl dieselReference
Engine (gross)54.3 kWReference
Engine (net)50.0 kWReference
DeutzReference
dieselReference
4-cylinderReference
liquid-cooledReference
Power (net)50.0 kWReference
Power (gross)54.3 kWReference
Starter typeelectricReference
Transmission
24-speed power shuttleReference
Typepower shuttleReference
Gears24 forward and reverseReference
PTO & Hydraulics
PTO (claimed)46.2 kWReference
Pump flow60.9 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift1936 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/540E/1000 (1.375)Reference
Zetor M70 attachments
front-end loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
