Tractor · 2013Unverified
Zetor Major 80
Zetor Major 80 — Model year 2013-20152015-20182019-2025 · 74 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
74 hp
Weight
3089 kg
Hover a source tag to verify
Overview
ManufacturerZetorReference
Utility tractorReference
Two- or four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Trailer brakespneumaticReference
Cab standard with optional air-conditioning.Reference
Engine
Zetor 4.2L 4-cyl dieselReference
Engine61.1 kWReference
Zetor 1105Reference
turbocharged dieselReference
4-cylinder 8-valveReference
liquid-cooledReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
EmissionsStage IIIAReference
Power61.1 kWReference
Rated RPM2200Reference
Starter typeelectricReference
Transmission
12-speed synchronizedReference
TypesynchronizedReference
Gears12 forward and reverseReference
Clutch280mm mechanical cerametallic discReference
PTO & Hydraulics
PTO (claimed)55.2 kWReference
Pressure180.0 barReference
Valves1 or 2Reference
Total flow50.0 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at ends)2651 kgReference
Rear PTOindependentReference
Clutchmechanical dry discReference
Rear PTO Type540/1000Reference
Rear PTO Type540/540EReference
Dimensions
Wheelbase220 cmReference
Weight3089 kgReference
Front tire7.5-15Reference
2WD Rear tire16.9-28Reference
2WD Standard tires (ag)Front: 7.5-15. Rear: 16.9-28Reference
4WD Standard tires (ag)Front: 11.2-24. Rear: 16.9-30Reference
Length421 cmReference
Width185 cmReference
Height (exhaust)265 cmReference
4WD Weight3089 kgReference
Electrical
Charging systemalternatorReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
