Tractor · 2017Unverified
Zetor Major HS 65
Zetor Major HS 65 — Major Series · 67 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
67 hp
Weight
2519 kg
Hover a source tag to verify
Overview
ManufacturerZetorReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Deutz 2.9L 4-cyl dieselReference
Fuel tank70.0 LReference
Engine (gross)50.0 kWReference
Deutz TCD 2.9 L4Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke92 x 110 mmReference
EmissionsTier IVReference
Power (gross)50.0 kWReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Oil capacity8.0 LReference
Coolant capacity10.0 LReference
Transmission
24-speed power shuttleReference
Typepower shuttleReference
Gears24 forward and reverseReference
Clutchdry discReference
Oil capacity10.4 LReference
Four gears in three ranges with two-speed main/creeper range shift.Reference
PTO & Hydraulics
PTO (claimed)46.2 kWReference
Typeopen centerReference
Valves2Reference
Pump flow39.0 lpmReference
Total flow60.9 lpmReference
Steering flow22.0 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at ends)1936 kgReference
Rear lift (at 24"/610mm)1430 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540/750/1000 (1.375)Reference
Dimensions
Wheelbase214 cmReference
Weight2519 kgReference
Front tire11.2-20Reference
Rear tire14.9-30Reference
Standard tires (ag)Front: 11.2-20. Rear: 14.9-30Reference
Length395 cmReference
Width183 cmReference
Height (cab)254 cmReference
Ground clearance43 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps95Reference
Charging volts12Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
