Tractor · 2017Unverified
Zetor Major HT 45
Zetor Major HT 45 — Major Series · 46 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
46 hp
Weight
1920 kg
Hover a source tag to verify
Overview
ManufacturerZetorReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Yanmar 2.2L 4-cyl dieselReference
Fuel tank60.0 LReference
Engine (gross)34.3 kWReference
Yanmar 4TNV88CReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke88 x 90 mmReference
EmissionsTier IVReference
Power (gross)34.3 kWReference
Rated RPM2800Reference
StarterelectricReference
Starter volts12Reference
Oil capacity6.7 LReference
Coolant capacity8.5 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
Oil capacity8.7 LReference
PTO & Hydraulics
PTO (claimed)25.8 kWReference
Typeopen centerReference
Valves2Reference
Pump flow36.0 lpmReference
Total flow54.9 lpmReference
Steering flow18.9 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)1503 kgReference
Rear lift (at 24"/610mm)1335 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase193 cmReference
Weight1920 kgReference
Front tire9.5-16Reference
Rear tire13.6-26Reference
Standard tires (ag)Front: 9.5-16. Rear: 13.6-26Reference
Industrial front12-16.5Reference
Industrial rear17.5L-24Reference
Length358 cmReference
Width162 cmReference
Height (cab)252 cmReference
Ground clearance35 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps70Reference
Charging volts12Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
