Tractor · 2010Unverified
Zetor Proxima Power 100
Zetor Proxima Power 100 — Model year 2010-20142014-2016 · 96 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
96 hp
Weight
3999 kg
Hover a source tag to verify
Overview
ManufacturerZetorReference
Utility tractorReference
Built in Brno, Czech RepublicReference
Four-wheel driveReference
Differential lockelectro-pneumaticReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakespneumaticReference
Trailer brakeshydraulicReference
Cab standard with optional air-conditioning.Reference
Engine
Zetor 4.2L 4-cyl dieselReference
Fuel tank174.9 LReference
Engine (net)71.6 kWReference
front-end loaderReference
Standard tires (ag)Front: 11.2-24. Rear: 16.9-30Reference
Zetor 1005Reference
turbocharged dieselReference
4-cylinder 8-valveReference
liquid-cooledReference
Displacement4.2 LReference
Bore/Stroke105 x 120 mmReference
EmissionsStage IIIReference
Rated Power (net)71.6 kWReference
Rated RPM2200Reference
Starter typeelectricReference
Transmission
24-speed three-speed power shiftReference
Typethree-speed power shiftReference
Gears24 forward and reverseReference
Clutchelectro-hydraulic wet discReference
PTO & Hydraulics
Pressure190.0 barReference
Valves3Reference
Total flow50.0 lpmReference
Rear TypeIIReference
Controlposition control and mechanical top-link draft sensingReference
Rear lift4282 kgReference
Rear PTOindependentReference
Clutchwet discReference
Rear PTO Type540/1000Reference
Rear PTO Type540/540EReference
Front PTO Type1000Reference
Dimensions
Wheelbase232 cmReference
Weight3999 kgReference
Front tire11.2-24Reference
Rear tire16.9-30Reference
Length390 cmReference
Width191 cmReference
Height271 cmReference
Ground clearance40 cmReference
Electrical
Charging systemalternatorReference
Attachment overview
Zetor 120K loaderReference
Zetor 120SLi loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
