Tractor · 2020Unverified
Zetor Utilix 55
Zetor Utilix 55 — Utilix Series · 49 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
49 hp
Weight
3770 to 4189 pounds
Hover a source tag to verify
Overview
ManufacturerZetorReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Two-post folding ROPS. Cab available with air-conditioning.Reference
Variants
CL 55gearReference
HT 55hydrostaticReference
Engine
Perkins 2.2L 4-cyl dieselReference
Engine (gross)36.3 kWReference
Perkins 404D-22Reference
dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement2.2 LReference
Bore/Stroke84 x 100 mmReference
EmissionsStage 3AReference
Rated Power (gross)36.3 kWReference
Rated RPM2800Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed mechanical shuttleReference
hydrostaticReference
Typemechanical shuttleReference
Gears16 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Typeopen centerReference
Rear valves2Reference
Mid valves2Reference
Pump flow36.3 lpmReference
Total flow55.6 lpmReference
Steering flow19.3 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)1529 kgReference
Rear lift (at 24"/610mm)1325 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase193 cmReference
Weight3770 to 4189 poundsReference
Front tire240/70R16Reference
Rear tire320/70R24Reference
Standard tires (ag)Front: 240/70R16. Rear: 320/70R24Reference
Industrial front12-16.5Reference
Industrial rear17.5L-24Reference
Length358 cmReference
R1 Width162 cmReference
R4 Width186 cmReference
Height (ROPS)259 cmReference
Height (cab)252 cmReference
ROPS1710 kgReference
Cab1900 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Capacities
Max capacity3324 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
