Tractor · 1991Unverified
AGCO Allis 5670
AGCO Allis 5670 — Utility tractor · 63 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
63 hp
Max power
41.5 kW
Weight
2449 kg
Hover a source tag to verify
Overview
DistributorAGCO AllisReference
ManufacturerSAMEReference
Utility tractorReference
Built in ItalyReference
Original price was $30,000 in 1999Reference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post ROPS. Optional canopy.Reference
Variants
5670ROPSReference
6670CabReference
Explorer II 70similar SAME modelReference
Engine
SLH 4.0L 4-cyl dieselReference
Fuel tank68.1 LReference
Engine51.5 kWReference
Drawbar (claimed)41.5 kWReference
Drawbar (tested)41.5 kWReference
SLH 1000.4AReference
dieselReference
4-cylinderReference
air-cooled inlineReference
Displacement4.0 LReference
Bore/Stroke105 x 116 mmReference
Power51.5 kWReference
Pre-heatingthermostartReference
Compression17:1Reference
Rated RPM2350Reference
Starter volts12Reference
Power at rated engine speed47.1 kWReference
Max power41.5 kWReference
Transmission
16-speed sync shuttleReference
24-speedReference
Typesync shuttleReference
Gears16 forward and reverseReference
Four synchronized gears in four ranges, with synchronized shuttle.Reference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
PTO (claimed)47.1 kWReference
PTO (tested)47.1 kWReference
Typeopen centerReference
Valves2Reference
Pump flow41.6 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)2249 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540/1000Reference
Dimensions
2WD Wheelbase231 cmReference
4WD Wheelbase224 cmReference
Weight2449 kgReference
Front tire7.50-16Reference
Rear tire16.9R30Reference
Ag front7.50-16Reference
Ag rear16.9R30Reference
2WD Length385 cmReference
4WD Length383 cmReference
Width237 cmReference
Height245 cmReference
2WD Front tread139 to 199 cmReference
4WD Front tread160 to 215 cmReference
Rear tread139 to 199 cmReference
5670 Serial Numbers
Location:Console, right sideReference
19911001Reference
19921143Reference
19931220Reference
19941588Reference
19951764Reference
19961964Reference
19972121Reference
19982241Reference
1999----Reference
20002339Reference
20012360Reference
20022370Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Test results
Diesel 12-speed 4WDJanuary 1986 - 1986, Link: OCED Tractor Test 1007 fileReference
PTO performanceReference
Fuel use14.0 l/hourReference
Drawbar performanceReference
Fuel use16.3 l/hourReference
Gear 1F used for power test.Reference
Max pull1208 kgReference
Gear 1F used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
