Tractor · 1991Unverified
AGCO Allis 5680
AGCO Allis 5680 — Utility tractor · 73 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
73 hp
Max power
46.3 kW
Weight
2721 kg
Hover a source tag to verify
Overview
DistributorAGCO AllisReference
ManufacturerSAMEReference
Utility tractorReference
Built in ItalyReference
Original price was $32,000 in 1997Reference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post ROPS. Optional canopy.Reference
Variants
5680ROPSReference
6680CabReference
Explorer II 80similar SAME modelReference
Engine
SLH 4.0L 4-cyl dieselReference
Fuel tank79.5 LReference
Engine59.7 kWReference
Drawbar (claimed)46.3 kWReference
Drawbar (tested)46.3 kWReference
SLH 1000.4AReference
dieselReference
4-cylinderReference
air-cooled inlineReference
Displacement4.0 LReference
Bore/Stroke105 x 116 mmReference
Power59.7 kWReference
Pre-heatingthermostartReference
Compression17:1Reference
Rated RPM2500Reference
Starter volts12Reference
Power at rated engine speed54.2 kWReference
Max power46.3 kWReference
Transmission
16-speed sync shuttleReference
24-speedReference
Typesync shuttleReference
Gears16 forward and reverseReference
Four synchronized gears in four ranges, with synchronized shuttle.Reference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
PTO (claimed)54.2 kWReference
PTO (tested)54.2 kWReference
Typeopen centerReference
Valves2Reference
Pump flow44.7 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)1900 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540/1000Reference
Dimensions
2WD Wheelbase235 cmReference
4WD Wheelbase231 cmReference
Weight2721 kgReference
Front tire7.50-18Reference
Rear tire16.9R34Reference
Ag front7.50-18Reference
Ag rear16.9R34Reference
2WD Length391 cmReference
4WD Length399 cmReference
Width194 cmReference
Height252 cmReference
2WD Front tread139 to 199 cmReference
4WD Front tread142 to 213 cmReference
Rear tread142 to 203 cmReference
5680 Serial Numbers
Location:Console, right sideReference
19911001Reference
19921090Reference
19931156Reference
19941222Reference
19951555Reference
19961601Reference
19971652Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Test results
Diesel 12-speed 4WD7/1987Link: OCED Tractor Test 1091 fileReference
PTO performanceReference
Fuel use16.7 l/hourReference
Drawbar performanceReference
Fuel use19.7 l/hourReference
Gear 3N used for power test.Reference
Max pull2658 kgReference
Gear 3N used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
