Tractor · 1991Unverified

AGCO Allis 9130

Name: AGCO Allis 9130
Brand: AGCO Allis

AGCO Allis 9130 — Row-Crop tractor · 135 hp. Reference specifications; pending source verification.

The AGCO Allis 9130 is a high-powered tractor, rated at 135 hp, categorising it among the more powerful machines in its class. Manufactured between 1991 and 1992, it features a 6-cylinder diesel air-cooled engine, which drives a four-wheel drive system via a hydrostatic transmission. The listed weight of the 9130 is 5579 kg, and it is intended for use on areas ranging from 200 to 800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

135 hp

Weight

5579 kg

Catalogue coverage

Variants represented

Richest spec table

41 rows

Recorded power

135 hp

Recorded weight

5579 kg

Transmissions

18-speed three-speed power shift

Production years

1991-1992

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorAGCO AllisReference

ManufacturerWhiteReference

Row-Crop tractorReference

Built in Coldwater, Ohio, USAReference

Original price was $62,000 in 1992Reference

Two- or four-wheel driveReference

Steeringhydrostatic powerReference

Engine

Deutz 6.1L 6-cyl dieselReference

Fuel tank340.7 LReference

DeutzReference

dieselReference

6-cylinderReference

air-cooledReference

Displacement6.1 LReference

Bore/Stroke102 x 125 mmReference

Rated RPM2400Reference

Starter volts12Reference

Transmission

18-speed three-speed power shiftReference

Typethree-speed power shiftReference

Gears18 forward and 6 reverseReference

Six forward gears, each with a three-speed power shift.Reference

PTO & Hydraulics

PTO (claimed)100.7 kWReference

TypeclosedReference

Valves3Reference

Pump flow90.8 lpmReference

Rear TypeII,IIIReference

Rear lift3271 kgReference

Rear PTOindependentReference

Rear PTO Type540, 1000Reference

Dimensions

Wheelbase304 cmReference

Weight5579 kgReference

Front tire11.00-16Reference

Rear tire18.4R38Reference

Ag front11.00-16Reference

Ag rear18.4R38Reference

9130 Serial Numbers

19897440-6018Reference

19911001Reference

199212500Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
