Tractor · 1991Unverified
AGCO Allis 9130
AGCO Allis 9130 — Row-Crop tractor · 135 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
135 hp
Weight
5579 kg
Hover a source tag to verify
Overview
DistributorAGCO AllisReference
ManufacturerWhiteReference
Row-Crop tractorReference
Built in Coldwater, Ohio, USAReference
Original price was $62,000 in 1992Reference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Engine
Deutz 6.1L 6-cyl dieselReference
Fuel tank340.7 LReference
DeutzReference
dieselReference
6-cylinderReference
air-cooledReference
Displacement6.1 LReference
Bore/Stroke102 x 125 mmReference
Rated RPM2400Reference
Starter volts12Reference
Transmission
18-speed three-speed power shiftReference
Typethree-speed power shiftReference
Gears18 forward and 6 reverseReference
Six forward gears, each with a three-speed power shift.Reference
PTO & Hydraulics
PTO (claimed)100.7 kWReference
TypeclosedReference
Valves3Reference
Pump flow90.8 lpmReference
Rear TypeII,IIIReference
Rear lift3271 kgReference
Rear PTOindependentReference
Rear PTO Type540, 1000Reference
Dimensions
Wheelbase304 cmReference
Weight5579 kgReference
Front tire11.00-16Reference
Rear tire18.4R38Reference
Ag front11.00-16Reference
Ag rear18.4R38Reference
9130 Serial Numbers
19897440-6018Reference
19911001Reference
199212500Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
