Tractor · 1994Unverified
AGCO Allis 9670
AGCO Allis 9670 — Row-Crop tractor · 175 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
175 hp
Max power
135.1 kW
Weight
16100 to 19400 pounds
Hover a source tag to verify
Overview
ManufacturerAGCO Allis (a part of AGCO)Reference
Row-Crop tractorReference
Original price was $85,000 in 1995Reference
Two- or four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockelectro-hydraulic rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Deutz 9.6L 6-cyl dieselReference
Fuel tank367.1 LReference
Drawbar (tested)113.5 kWReference
Deutz BF6L513RReference
turbocharged dieselReference
6-cylinderReference
air-cooledReference
Displacement9.6 LReference
Bore/Stroke125 x 130 mmReference
Pre-heatingether injectionReference
Compression15.8:1Reference
Rated RPM2300Reference
Starter volts12Reference
Oil capacity22.7 LReference
Max power135.1 kWReference
Power at rated engine speed130.6 kWReference
Max power113.5 kWReference
Transmission
18-speed full power shiftReference
Typefull power shiftReference
Gears18 forward and 9 reverseReference
Clutchhydraulic wet discReference
PTO & Hydraulics
PTO (claimed)130.5 kWReference
PTO (tested)135.1 kWReference
Typeclosed center pressure-compensatingReference
Pressure172.4 barReference
Rear valves3 or 4Reference
Pump flow87.1 lpmReference
Rear TypeIII/IIReference
Controllower-link draft sensingReference
Rear lift (at 24"/610mm)3855 kgReference
Rear lift (at 24"/610mm)4490 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type1000Reference
Power at rated PTO speed135.1 kWReference
Dimensions
2WD Wheelbase308 cmReference
4WD Wheelbase292 cmReference
Weight16100 to 19400 poundsReference
Front tire11.00-16Reference
2WD Rear tire20.8R38Reference
2WD Standard tires (ag)Front: 11.00-16. Rear: 20.8R38Reference
4WD Standard tires (ag)Front: 16.9R28. Rear: 20.8R38Reference
Length508 cmReference
Width243 cmReference
Height (cab)306 cmReference
2WD Clearance (front axle)58 cmReference
4WD Clearance (front axle)55 cmReference
Clearance (drawbar)43 cmReference
Bar rear axle98 by 2438 mmReference
Bar rear axle98 by 2921 mmReference
2WD Front tread157 to 208 cmReference
4WD Front tread155 to 221 cmReference
Rear tread162 to 272 cmReference
Rear tread162 to 320 cmReference
2WD Shipping7302 kgReference
4WD Shipping8164 kgReference
4WD Operating8799 kgReference
9670 Serial Numbers
Location:Console, right sideReference
1994961001Reference
1995961501Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps105Reference
Batteries2Reference
Battery CCA580Reference
Battery volts12Reference
Test results
Diesel 18-speed 4WDOctober 6 - 21, 1994Link: OCED Tractor Test 1683 fileReference
PTO performanceReference
Fuel use41.3 l/hourReference
Fuel use43.5 l/hourReference
Drawbar performanceReference
Gear 7 used for power test.Reference
Max pull8504 kgReference
Gear 4 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
