Tractor · 2006Unverified
AGCO LT90A
AGCO LT90A — LT-A Series · 92 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
92 hp
Max power
69.9 kW
Weight
8820 to 9940 pounds
Hover a source tag to verify
Overview
ManufacturerAGCOReference
Utility tractorReference
Built in Beauvais, FranceReference
Two- or four-wheel driveReference
Final drivesinboard planetaryReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional.Reference
Engine
Sisu 4.4L 4-cyl dieselReference
Fuel tank129.8 LReference
Fuel tank186.6 LReference
Engine82.0 kWReference
SisuReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke108 x 120 mmReference
Power82.0 kWReference
Air cleanerpaper element with water separatorReference
Compression18.5:1Reference
Rated RPM2200Reference
Starter volts12Reference
Max power69.9 kWReference
Power at rated engine speed68.4 kWReference
Transmission
16-speed full power shiftReference
Typefull power shiftReference
Gears16 forward and reverseReference
Clutchelectro-hydraulic wet discReference
PTO & Hydraulics
PTO (claimed)67.1 kWReference
PTO (tested)69.9 kWReference
Typeopen centerReference
Typeclosed centerReference
Valves2 to 4Reference
Total flow98.4 lpmReference
Total flow109.8 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)3545 kgReference
Rear lift (at 24"/610mm)4168 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1980Reference
Engine RPM1000E@1550Reference
Engine RPM1000@2000Reference
Power at rated PTO speed69.9 kWReference
Dimensions
Wheelbase273 cmReference
Weight8820 to 9940 poundsReference
Front tire14.9R24Reference
Rear tire18.4R34Reference
Ag front14.9R24Reference
Ag rear18.4R34Reference
Length420 cmReference
Height (Folded ROPS)158 cmReference
Height (cab)279 cmReference
2WD ROPS Weight4000 kgReference
4WD Cab Weight4508 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Test results
Diesel 16 speed 4WDMay 24 - 30, 2007Link: Nebraska Tractor Test 1902 fileReference
PTO performanceReference
Fuel use20.4 l/hourReference
Fuel use22.0 l/hourReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
