Tractor · Unverified

Bima 285

Name: Bima 285
Brand: Bima

Bima 285 — Four-wheel Drive (4WD) tractor · 287 hp. Reference specifications; pending source verification.

The Bima 285 is a tractor with an approximate power rating of 287 hp, placing it at the higher end of its class. It is equipped with a 6-cylinder turbocharged diesel liquid-cooled engine and four-wheel drive, in conjunction with a hydrostatic transmission. The tractor's operating weight is specified at 12500 kg. It is suitable for use on operational areas exceeding 1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

287 hp

Weight

12500 kg

Catalogue coverage

Variants represented

Richest spec table

40 rows

Recorded power

287 hp

Recorded weight

12500 kg

Transmissions

hydrostatic

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerBimaReference

Four-wheel Drive (4WD) tractorReference

Built in FranceReference

Drive4x4 4WDReference

Articulated power steeringReference

Cab standardReference

Engine

Fiat 13.8L 6-cyl dieselReference

Mercedes-Benz 12.0L 6-cyl dieselReference

Caterpillar 10.5L 6-cyl dieselReference

Engine214.0 kWReference

Fiat 8210Reference

turbocharged dieselReference

6-cylinderReference

liquid-cooledReference

Displacement13.8 LReference

Bore/Stroke137 x 156 mmReference

Power214.0 kWReference

Rated RPM2000Reference

Starter typeelectricReference

Mercedes-Benz OM 447AReference

Displacement12.0 LReference

Bore/Stroke128 x 155 mmReference

Power212.5 kWReference

Rated RPM2100Reference

Caterpillar 3306Reference

Displacement10.5 LReference

Bore/Stroke121 x 152 mmReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (4-ranage)Reference

Dimensions

Wheelbase400 cmReference

Weight12500 kgReference

Front tire20.8x38Reference

Rear tire20.8x38Reference

Ag front20.8x38Reference

Ag rear20.8x38Reference

Length674 cmReference

Width249 cmReference

Height (cab)385 cmReference

Shipping weight12500 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
