Tractor · 1985Unverified

CaseIH 485 Orchard

CaseIH 485 Orchard — Orchard/Vineyard tractor · 53 hp. Reference specifications; pending source verification.

The CaseIH 485 Orchard is a compact tractor with a rated power output of 53 hp, making it suitable for smaller-scale operations. Manufactured from 1985 to 1991, it features a 3-cylinder diesel liquid-cooled engine, a two-wheel drive system and a powershift transmission. Weighing 2172 kg, this tractor is designed for use in areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
53 hp
Weight
2172 kg

Catalogue coverage

Variants represented
2
Richest spec table
75 rows
Recorded power
53 hp
Recorded weight
2172 kg
Transmissions
8-speed synchromesh
Production years
1985-1991
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIHReference
Orchard/Vineyard tractorReference
Two-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Open operator station.Reference

Variants

485utilityReference
485-OorchardReference

Engine

CaseIH 2.9L 3-cyl dieselReference
Engine (gross)39.5 kWReference
Engine (net)37.3 kWReference
CaseIH D-176Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke99 x 129 mmReference
Power (net)37.3 kWReference
Power (gross)39.5 kWReference
Air cleanerdryReference
Pre-heatingether injectionReference
Compression16:1Reference
Rated RPM2200Reference
Idle RPM700-2400Reference
Torque188.5 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity6.5 LReference
Coolant capacity11.4 LReference

Transmission

8-speed synchromeshReference
16-speed two-speed power shiftReference
TypesynchromeshReference
Gears8 forward and 4 reverseReference
Clutch279mm dry discReference
Oil capacity34.0 LReference
Typetwo-speed power shiftReference
Gears16 forward and 8 reverseReference

PTO & Hydraulics

PTO (claimed)31.3 kWReference
Hydraulic system34.1 LReference
Capacity34.1 LReference
Pressure172.4 barReference
Pump flow60.2 lpmReference
Pump flow64.3 lpmReference
Steering flow9.5 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference

Capacities

Fuel70.0 LReference

Dimensions

Wheelbase183 cmReference
Weight2172 kgReference
Front tire9.00x10Reference
Rear tire18.4x16.1Reference
Ag front9.00x10Reference
Ag rear18.4x16.1Reference
Ag front6.00x16Reference
Ag front7.50x15Reference
Ag front7.50x16Reference
Ag front9.5x15Reference
Ag rear13.6x28Reference
Ag rear14.9x24Reference
Ag rear21.5x16.1Reference
Width177 cmReference
Height (steering wheel)130 cmReference
Height (hood)121 cmReference
Shipping weight2172 kgReference
Clearance (drawbar)22 cmReference
Flange rear axleReference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Battery volts12Reference
Battery AH93Reference

Speeds

With 18.4x16.1 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
