Tractor · 2006Unverified
CaseIH MX215 Magnum
CaseIH MX215 Magnum — Magnum Series · 178 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
178 hp
Max power
160.9 kW
Weight
9541 kg
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Row-Crop tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Independent hydraulic wet disc brakesReference
Engine
CNH 8.3L 6-cyl dieselReference
Engine164.8 kWReference
Drawbar (tested)113.0 kWReference
CNHReference
intercooled turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement8.3 LReference
Bore/Stroke114 x 135 mmReference
Power164.8 kWReference
Air cleanerdual paper elementsReference
Compression17:1Reference
Rated RPM2000Reference
Torque1902.5 NmReference
Torque RPM1400Reference
Starter volts12Reference
Oil capacity20.8 LReference
Coolant capacity22.7 LReference
Max power160.9 kWReference
Power at rated engine speed132.4 kWReference
Max power113.0 kWReference
Transmission
18-speedReference
19-speedReference
23-speedReference
TransmissionPowershiftReference
Gears18 forward and 4 reverseReference
TransmissionPowershift - overdriveReference
Gears19 forward and 4 reverseReference
TransmissionCreeperReference
Gears23 forward and 6 reverseReference
PTO & Hydraulics
PTO (claimed)130.5 kWReference
PTO (tested)160.9 kWReference
Hydraulic system172.2 LReference
TypePFCReference
Capacity172.2 LReference
Valves3 to 5Reference
Total flow146.1 lpmReference
Total flow219.5 lpmReference
Rear TypeIIIReference
Rear lift6332 kgReference
Rear lift7243 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Power at rated PTO speed160.9 kWReference
Capacities
Fuel681.3 LReference
Dimensions
Wheelbase300 cmReference
Weight9541 kgReference
Height326 cmReference
Operating weight9541 kgReference
Electrical
Charging amps150Reference
Charging amps175 (optional)Reference
Battery CCA2000Reference
Battery volts12Reference
Test results
Diesel 19 speed 4WDMay 8 - 18, 2007Link: OCED Tractor Test 565 fileReference
PTO performanceReference
Fuel use49.6 l/hourReference
Fuel use43.5 l/hourReference
Drawbar performanceReference
Fuel use43.9 l/hourReference
Gear 7 used for power test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
