Tractor · 1998Unverified
CaseIH MX80C
CaseIH MX80C — MXC Series · 67 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
67 hp
Max power
50.6 kW
Weight
9921 to 10580 pounds
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Utility tractorReference
Built in Doncaster, EnglandReference
Original price was $53,000 in 1999Reference
Four-wheel driveReference
Power steeringReference
Differential hydraulic wet disc brakesReference
Cab standard.Reference
Variants
MC80similar McCormick Intl modelReference
Engine
Perkins 4.0L 4-cyl dieselReference
Engine62.6 kWReference
Drawbar (tested)42.7 kWReference
Perkins 1004-4TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement4.0 LReference
Bore/Stroke100 x 127 mmReference
Power62.6 kWReference
Fuel systemdirect-injection with mechanical governor, rotary injection pump with 5-hole nozzlesReference
Air cleanerdual paper elementsReference
Compression17.25:1Reference
Rated RPM2200Reference
Starter volts12Reference
Oil capacity8.8 LReference
Coolant capacity15.7 LReference
Max power50.6 kWReference
Power at rated engine speed50.0 kWReference
Max power42.7 kWReference
Transmission
16-speed partial power shiftReference
32-speed creeperReference
Typepartial power shiftReference
Gears16 forward and 12 reverseReference
Clutchhydraulic wet discsReference
Four power shift speeds (1-4) in four synchronized ranges (I-IV) with power shuttle. Three ranges in reverse.Reference
TypecreeperReference
Gears32 forward and 24 reverseReference
PTO & Hydraulics
PTO (claimed)50.0 kWReference
PTO (tested)50.6 kWReference
Hydraulic system66.2 LReference
Typeclosed center pressure-flow compensating (PFC)Reference
Capacity66.2 LReference
Pressure203.4 barReference
Valves2 to 4Reference
Pump flow94.6 lpmReference
Total flow109.4 lpmReference
Rear TypeIIReference
Controlelectronic lower linkReference
Rear lift (at 24"/610mm)3807 kgReference
Rear PTOindependentReference
Clutchelectrically-actuated wet discReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1875Reference
Engine RPM1000@2210Reference
Capacities
Fuel189.2 LReference
Dimensions
Wheelbase242 cmReference
Weight9921 to 10580 poundsReference
Front tire12.4R-24Reference
Rear tire16.9-34Reference
Ag front12.4R-24Reference
Ag rear16.9-34Reference
Length433 cmReference
Height (cab)280 cmReference
Shipping weight4500 kgReference
Operating weight4799 kgReference
MX80C Serial Numbers
Location:Serial plate on front-left corner cab postReference
1998JJE1050021Reference
1999JJE1052034Reference
2000JJE1053772Reference
2001JJE1055506Reference
2002JJE1056230Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps95Reference
Charging volts12Reference
Batteries2Reference
Battery CCA700Reference
Battery volts12Reference
Test results
Diesel 16-speed 4WDMarch 1 - 31, 2000Link: OCED Tractor Test 1930 fileReference
PTO performanceReference
Fuel use17.0 l/hourReference
Fuel use17.8 l/hourReference
Drawbar performanceReference
Fuel use18.2 l/hourReference
Gear 2-II used for power test.Reference
Max pull5025 kgReference
Gear 2-I used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
